Image Encoding in MRI & Bayesian Image Reconstruction

Suyash P. Awate¹
¹Indian Institute of Technology Bombay, India

Synopsis

Keywords: Image acquisition: Image processing

This talk presents the fundamentals underlying magnetic resonance imaging, including various parallel-imaging schemes, and the fundamentals of (Bayesian) image reconstruction methods from subsampled multicoil k-space data.

Slide #1

Slide #2

Slide #3

Slide #4

Slide #5

Slide #6

Slide #7

Slide #8

Slide #9

Slide #10

Slide #11

Slide #12

Slide #13

Slide #14

Slide #15

Slide #16

Slide #17

Slide #18

Slide #19

Slide #20

Slide #21

Slide #22

Slide #23

Slide #24

Slide #25

Slide #26

Slide #27

Slide #28

Slide #29

Slide #30

Proc. Intl. Soc. Mag. Reson. Med. 32 (2024)
